Classification of Grinding Machines

With the increase in the number of high-precision and high hardness machine parts, the development of precision casting and precision forging technology, the performance, variety, and output of grinding machines continue to improve

1) External cylindrical grinder:

This is a common basic series mainly used for polishing cylindrical and conical outer surfaces.

Internal Grinding Machine

This is a common basic series mainly used for grinding cylindrical and conical inner surfaces.

. In addition, there is a grinder used for internal and external grinding

3) Coordinate grinder:

Internal cylindrical grinder with precise coordinate device.

4) Centerless Grinding Machine:

The machined parts are fixed without cores, usually between the guide wheel and the bracket.

. Turn the steering wheel Grinding is mainly used for cylindrical grinding machines Such as bearings, shaft supports, etc

Surface Grinding Machine

Grinding machines are mainly used to grind parts on a flat surface.

Handheld grinding machines are suitable for processing small-sized, high-precision workpieces in various forms such as arc, flat, and bevel. D. B. Educational grinding machines are suitable for processing large machined parts with low precision, unlike manual grinding machines

Sand belt grinder:

A grinder used for quickly moving belts.

(7) Honing machine:

Mainly used for machining various cylindrical holes.

(including smooth, axially or radially continuous surface holes, through holes, blind holes, and multi-stage holes) as well as tapered, elliptical, and cycloid holes

8) Grinding machine:

A machine tool used for grinding the flat or cylindrical inner and outer surfaces of machined parts.

(9) Track grinder:

Mainly used for grinding the surface of guided machine tools.

10) Tool grinding machine:

Grinding machine for grinding tools.

11) Multipurpose grinder:

It is a grinder used to grind the inner and outer surfaces of cylindrical bodies and cones or planes, and can grind various workpieces with servo transmission devices and accessories.

12) Specialized Grinding Machine:

A specialized machine tool used for grinding certain parts.

. Grinding objects can be divided into the following groups: grinding, crank, cam, tooth profile, thread grinding, etc

13) End grinder:

Gear end face grinder.
